Description
QPAC 30W Batten LED Single – Easy Release Linear Batten – 30w, 4000k, 1500mm – IP20 – Epistar Chipset & Q-Drive
Code: QPAC-30-1500NW
| System Power | 30W / 60W |
|---|---|
| LED Chipset | Epistar |
| Wattage type | Fixed |
| Driver Manufacturer | Q-Drive |
| Colour Rendering Index (CRI) | >80 |
| Lumen Output | 3600Lm or 7200Lm |
| LED Efficacy | 120Lm/cW |
| Power Factor | >0.9 |
| IP Rating | IP20 |
| Dimmable | Contact office |
| Diffuser type | Polycarbonate |
| Colour Temperature | 4000K (Fixed) or 3000K/4000K/6000K (Tri-Colour) |
| Housing Material | Iron |
| Operating temperature | -20 to +40 ℃ |
| Weight | 1.9kg (30W) or 2.08kg (60W) |
| Input Voltage | 220V – 240V AC, 50-60Hz |
| Dimensions | 1500mm x 72mm x 72.5mm |
| ECA Scheme Compliant | Yes |
Technical Drawings:
