Neolink AC1200 Dual Band WiFi Ceiling Mount Access Point

Neolink AC1200 Dual Band WiFi Ceiling Mount Access Point

Code: NEO-AC-LR

The NEO-AC-LR Ceiling Mount Access Point is a wireless networking solution crafted to enhance your connectivity. With advanced technology and robust features, this access point is ideal for demanding environments, providing a superior connectivity experience. Ensures excellent performance with 802.11ac featuring MU-MIMO (Wave 2) and a wireless range extending up to 170 meters.

Easily manage, configure, and control the device remotely from anywhere globally using the Neolink app (compatible with iOS and Android) or through https://myneocloud.com.

In a multi-Access Point setup, seamless roaming (802.11k and 802.11v) enables swift transitions to the access point with the best signal strength during movement between Access Points.

Features:

• 1200 Mbps WiFi speed – Utilizing 2.4 GHz/5 GHz 802.11ac Wave 2 Dual-Band technology.
• Gigabit PoE – Offers a speed ten times faster than 10/100 Fast Ethernet.
• Up to 170m WiFi Range – Long-Range Omni-Directional Antennas provide an extensive wireless range.
• Cloud Management – Allows remote configuration, status checking, and access through Web/APP and more.

Specification:

• 2.4 GHz data rate: 300 Mbps
• 5 GHz data rate: 867 Mbps
• 1x 802.3at PoE Gigabit LAN Port
• WiFi Standards: 802.11 ac/v/r/k/n/g/b/a
• Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2)
• 2×2 MU-MIMO
• Zero Wait DFS
• Max SSID: 2.4 GHz: 8, 5GHz: 4
• Antenna: 2 x 4 dBi
• 2.4 GHz Max. TX Power: 26 +/- 1.5 dBm
• 5 GHz Max. TX Power: 26 +/- 1.5dBm
• Beamforming supported
• VLAN: 802.1Q & SSID to VLAN mapping
• WMM: Voice, Video, Best Effort, and Background
• Guest Traffic Isolation
• Software Watchdog
• Power Save mode
• Max. Concurrent Clients: 256
• Mounting: Wall/Ceiling (kits included)
• Protection: Lightning =6kV, ESD, Air discharge: ±8kV, Contact discharge: ±4kV
• Cloud Management: Configuration, Status, Web/APP & more
• Operating Temperature: -10°C ~ 45°C (14F ~ 113F)
• Power method: 802.3at PoE or 24V Passive PoE
• Power supply: 24V Passive PoE Gigabit Injector (included)
• Power consumption: <11.5W
• Dimensions (W x D): 176 x 43.5 mm

NEO-AC-LR
Long Range 802.11ac Wave 2 WiFi 5 Access Point
